Klein Tools’ VDV226-005 crimping tool is a modular crimp-connector installation tool for voice and data applications with the Pass-Thru RJ45 connector plug. It crimps and trims pass-thru RJ45 connectors onto paired conductor cables (round STP/UTP cables).

Ridgid’s RE 60-MLR manual hydraulic crimping tool features a very slim crimp head design that can be rotated 330 degrees, allowing easy access to cables even in the most confined panel spaces. It comes with a blow-molded plastic carrying case with space for 13 crimping dies.

Hilti’s NCR 60 D-22 cordless, dieless indent crimper is designed for crimping aluminum and copper cable lugs and connectors, standard-strand aluminum and copper cables and solderless terminals. It runs on the Nuron battery platform.

Greenlee’s EK1550SLX 15-ton crimper ­features a new C-head design with optimized weight balance for ergonomics. It has a 350-degree head rotation to access tight spaces and a new built-in alignment guide. It is designed for crimping large-capacity conductors and connectors in overhead and underground applications.

ABB’s TBZ3 crimping tool is a ratchet type hand tool. It is front loading and is designed for insulated cord ends between 0.5 and 6 mm². It is 195 mm long and has a mechanism to ensure a full compression.

Ideal Industries’ ratchet crimp tool crimps insulated or bare terminals and splices on 10–22 AWG wire. The ratchet action prevents release prior to crimp connection to ensure uniform crimps. The vinyl-coated handles provide a solid, comfortable grip, and it includes a release mechanism.

Channellock’s 909CB crimper/cutter has a center cut design aligns cutting edges in the center of the plier head for leverage and to maneuver into tight places. It is designed for use on insulated and noninsulated connections and terminals using 10–22 AWG wire.

Knipex’s 97 51 13 crimping pliers have an adjustable retaining bracket for all common RJ-45 plugs with closed and nonclosed housings. There are dual-crimping points for equal and balanced crimping pressure. It is used for cable cutting and round cable stripping.

Crescent Tool’s 8-in. wire crimper features extended-length handles for leverage, yielding much lower force to crimp junctions. Laser-etched wire sizes provide easy-to-read size markings. It has a drop-forged diagonal-cut end and crimpers for high-strength, pinch-style cutting. It works on most common residential and commercial wire sizes.

Burndy’s Patriot PAT81K2 series dieless hydraulic-crimping tool features an over-molded handle for comfort and improved grip. The battery hydraulic crimper include 6 tons of crimping power, 360-degree head rotation and mechanical ram release to conserve battery power.

Greenlee’s 12-ton LPK1230 crimping tool features a relief valve that signals the operator when the crimp is complete. It is powered in the advance and retract directions to prevent hang-ups, and no high-pressure intensifier is required. The jaw opening is 1.2 in., and the head rotates for tool positioning.

Milwaukee Tool’s manual lineman’s crimper features rubberized handles to enhance users’ grip for use while wearing PPE. It is made with a fiberglass core and absorbs vibration. It features integrated carabiner loops to safely pass up a handline or hang from a bucket, and the die-labeled tips allow linemen to quickly identify the tool.

Burndy’s PAT46T3 18V DC battery crimper has a Track Trace Transmit intelligence feature to provide crimping information. It features an LED work light and a red/green LED to validate output force. Users can transmit by Bluetooth and sync data to the cloud. It traces individual crimps with comments and output force validation.

Ridgid’s RE 12-M 12-ton manual hydraulic crimp tool features a low handle force to reduce hand strain and user fatigue. The head stand allows for one-person, one-handed operation. It has 13 slots for crimping dies in the carrying case with special slot decals for die identification and retrieval. The head rotates 330-degrees to access tight spaces.

ABB’s 950X series crimping tool features integrated range-taking dies for crimping wire ferrules within the range of 0.14–10.00 mm2/26–8 AWG. It features a ratchet-release mechanism for clearing obstructions, and the nonslip handle features holes for safety strap attachments. The range-taking design does not require the user to identify the proper die or nest to use, which minimizes the risk of mistakes or improper crimps. The ergonomic design helps to reduce user strain.

Channellock’s 909 9 1/2-in. crimping pliers feature a sleek nose design to get into tight places and a laser heat-treated mating edge. It is insulated and noninsulated for solderless connections and terminals. It cuts and crimps 10–22 AWG wire.

Burndy’s PAT46LWL5 18V DC Patriot battery-operated latch head crimper features a 2-in. jaw opening and a 355-degree head rotation. It is ergonomically balanced, lightweight and comes with a 120V AC charger. The crimp force capacity is 15 tons.

Burndy’s 444SL5 Patriot series 18V, lithium-ion dieless battery crimper features a C-head, dieless system with range-taking capability. It has a 335-degree head rotation. Its force capacity is 11 tons. It is hydraulic self-contained.

iToolCo.’s 12-ton coreless, dieless crimper is lightweight and battery-operated. It features a swivel-head design and weather-resistant housing. It includes a flashlight and an audible bypass when predetermined pressure is achieved. It features trigger and release buttons and is ergonomically balanced.

Hilti’s universal cordless crimper and cutter tool works with all interchangable jaws. Jaws retract automatically after completing an operation. It is a compact and light inline tool for access and maneuverability. The head rotates 350 degrees, and the approximate cycle time is 4 seconds. It offers a crimping force of 53 kN, and it crimps copper and aluminum conductors.

Hilti’s 60A dieless crimper features a pressure sensor to ensure correct crimping operations. A dieless operation eliminates the risk of wrong die selection. The piston retracts automatically after crimping and cutting.

Klein Tools’ forged wire crimper with stripper and cutter strips 10-18 AWG stranded wire and crimps 10-22 AWG insulated and noninsulated terminals and connectors. It features a hardened wire cutter in the nose, and the shear cutter below the rivet cuts copper and aluminum wire. The jaw is manufactured from forged steel for durability, and the textured grips enhance dexterity and integrated hang holes. It has tethering capabilities and
molded grips.

Greenlee’s 12-ton crimper features an LED display screen that displays pressure and tool diagnostics with real-time tool feedback. It includes a pressure sensor that monitors the crimping force of each movement and provides the operator with an alert if the force is below specifications. It automatically retracts when the crimping cycle is complete. The forward handle position improves tool balance, and the tacky grip areas make holding the tool easier.

Milwaukee Tool’s M18 Force Logic 15T crimper has an in-line design, a centered grip for one-handed use and a 350-degree rotating head. Its quick release and push-to-close pin design provides access around splices and in crowded environments. Its predictive force monitoring feature constantly measures force output to deliver consistent speed. A precrimp battery check automatically ensures enough battery charge to fully complete each crimp.

Klein Tools’ Klein-Kurve wire stripper/crimper multitool is designed for voice/data/video professionals. It crimps four connector types, twists, loops and strips solid and stranded wires, and shears 6–32 and 8–32 screws. It has a reinforced head, precision shear-type cutting blades and a tip for grabbing, pulling and bending wires.

ABB’s 26-in. ratchet crimper is designed for use with copper and aluminum lugs and splices. It can hold 250 MCM to 8 AWG copper cable and 10 to 4/0 AWG aluminum cable.

Gardner Bender’s F-Type compression crimp tool creates a permanent, watertight-sealed connection on RG-6, RG-6 quad and RG-59 connectors. It has a swing-locking loop to save storage space.

ABB’s Smart Tool+ dieless crimper can scan lug characteristics, automatically configure itself to deliver a solid crimp, check for quality in a finished crimp and load data to the cloud for storage and retrieval.

Platinum Tools’ EZ-RJ12/11 die is used to terminate EZ-RJ12/11 connectors. It is interchangeable and reversible when used with EXO crimp frame. It includes a single-cycle crimp and flush trim, and connectors lock into the tool for correct positioning during crimp. It can also crimp other standard “non-EZ” or pass-through style connectors.



Phoenix Contact’s Crimpfox Duo 10 crimping pliers have a rotating die that permits frontal or lateral insertion of ferrules and a locking mechanism keeps the die in position. It self-adjusts to accommodate single and twin ferrules, and 26-8 AWG single wires or 2x20 to 2x12 AWG twin ferrules.

Platinum Tools’ EXO Crimp Frame RJ45 crimp tool can terminate multiple sizes of cables and conductors. The crimp frame has two interchangeable dies that work with EZ-RJ45 (Cat 5E/6) and ezEX-RJ45 (Cat 6/6A) connectors. The connectors lock into the tool for correct positioning during crimp. It features single-cycle crimp and flush trim, reversible die for ambidextrous operation, a push-button lock, an ergonomic comfort grip, a hardened steel blade and more. Its design allows for future upgrades by purchasing a new die.

Klein Tools' Pass-Thru modular crimper cuts, strips and crimps STP/UTP paired-conductor cables. It features a full-cycle ratchet mechanism, an on-tool wiring guide and heat-treated blades. It can accommodate 28–22 AWG flat or round cables and solid or stranded telephone and data cables.

Automation Direct’s self-adjusting crimping tool is designed for crimping insulated and noninsulated ferrules and wire end sleeves. It is available in square and hexagonal crimp styles, and it features ergonomically shaped handles and a nonslip grip pad for applying pressure against a surface. It adjusts to wire sizes from 26–8 AWG.


Ridgid’s 12-ton, manual, hydraulic crimp tool is designed for wire termination and grounding applications to crimp compression lugs and connectors onto copper, aluminum and ACSR wire and grounding rods. The C-shaped head has a 1.65-in. jaw opening and a 330-degree head rotation. It is large enough for applications up to 1,000 MCM.


Greenlee’s K05-Syncro crimping tool can crimp 8 AWG–1/0 AWG copper. Die size is indicated using color coding on the dies and a lug sizer indicator on the dial. The dial allows for one-handed die change, rotating both dies at the same time.


Dewalt’s DCE300 U-type died crimper is enabled with the built-in crimp-connect system, which reports and prints the date, time, force and successfully completed crimp cycles as well as the tool’s calibration and service history. An LED panel powers the tool on and off and indicates battery status, cycle completion and whether recalibration or service is needed. It has an LED work light and a shoulder strap.
