As lighting systems evolve from simple illumination devices into connected infrastructure, the industry is placing more emphasis on open, interoperable standards. While many control platforms still rely on proprietary hardware and software, open standards are becoming increasingly relevant.

A significant player in standards is Zhaga-D4i (zD4i). It combines a standardized plug-in interface for sensors and communication modules with a common digital language for data exchange. For electrical contractors, this framework can simplify installation, improve upgradability and create new opportunities for offering connected lighting solutions.

Zhaga

Founded in 2010, the Zhaga Consortium, Piscataway, N.J., set out to create globally recognized mechanical and electrical interfaces for LED components. These interfaces are organized into a series of “books,” or specifications describing mating dimensions, electrical characteristics and functional requirements for various types of LED components.

Although Zhaga’s broader mission—interchangeable LED engines and drivers—has not seen heavy adoption in the United States, one  area has gained significant interest: the interface between a luminaire and the smart devices attached to it. This demand has been driven by outdoor lighting applications, where cities, utilities and property owners increasingly want luminaires capable of hosting sensors, wireless radios and monitoring equipment.

Earlier efforts such as ANSI C136.41, which added dimming capability to the familiar locking-type photocontrol receptacle, helped push outdoor controls forward. But these legacy connectors were never designed for the more complex, data-rich applications now common in smart-city deployments.

To address this, Zhaga introduced Book 18 in 2018. Now in its fourth edition (released in 2025), Book 18 defines how a smart node physically attaches to an outdoor LED luminaire, receives power and exchanges digital information with the driver. In effect, Book 18 serves as the socket standard for modern connected outdoor lighting.

DALI D4i

Around the same time, the DALI Alliance expanded its DALI-2 standard to better support internet of things (IoT) and luminaire-level control. Called D4i, this extension provides a consistent method for LED drivers, sensors and data-harvesting devices to communicate inside the luminaire. It requires drivers to store and share useful operational data such as power consumption, device identification, temperature information, diagnostics and lifetime energy reporting.

Zhaga-D4i certification

With Zhaga’s Book 18 managing the physical and electrical interface and the DALI Alliance’s D4i managing the digital handshake, the two organizations partnered to create the zD4i product certification.

A zD4i-certified luminaire is designed and tested to ensure that any properly certified smart node—a sensor, GPS module, photocell or wireless networking device—can be plugged directly into the luminaire and immediately operate as intended.

For ECs, zD4i facilitates installation, as nodes plug directly into the luminaire’s Book 18 port to receive low-voltage power. Projects that start with basic occupancy sensing and photocontrol are positioned to later adopt more advanced options such as environmental sensors and wireless networking. Because it requires the luminaire to provide operational and energy data, systems based on zD4i can report failures, track runtime and verify energy savings. Nodes can be added and replaced as needed using the standard connections and with a choice of vendor, as long as the node complies with zD4i.

For indoor applications, Book 20 serves a similar role by presenting a plug-and-play interface for sensors and communication modules within indoor luminaires. Though adoption in the United States is still emerging, zD4i indoor luminaires based on Book 20 are controls-ready, able to accept upgraded controls after installation.

ZD4i applications include occupancy and vacancy sensing, daylight-responsive control, IoT data collection, wireless network expansion and asset tracking and space-usage analytics. These functionalities are supported by NEMA’s ANSI C137, including the latest release, ANSI C137.4-2025.

This option can support “smart retrofits” where the existing luminaires are high-quality but lack modern sensing or control capabilities.

When it comes to connecting the luminaire to a network, note that zD4i only governs the interface inside the luminaire. It does not dictate how one luminaire communicates with another. Once a zD4i node is installed, the luminaire can join a network using whichever technology the node supports to access the full range of applications. Common options include Bluetooth Mesh, Zigbee and other solutions, whichever approach best matches the project requirements.

Standards fuel progress. Lighting is increasingly becoming part of a larger digital ecosystem. As owner interest in asset tracking, environmental data, adaptive lighting and integration with building automation systems grows, open and interoperable interfaces will become more valuable.

zD4i positions luminaires as field-upgradeable platforms that can adapt to new technologies without replacing the luminaire or rewiring the system. As books 18 and 20 continue to evolve and as D4i gains support, contractors can expect more manufacturers and projects to specify these standards.
